[Introduction]: A belt feeder with heave pressure bearing
[Capacity]: 10~450t/h
[Improvement]: Speed adjustment motor, adjusting the feeding volume by changing belt speed
Belt feeder is widely used in metallurgy, mineral processing, building materials, coal, hydropower and other departments for transporting 0.5~2.5t bulk density materials. According to the technological requirements, it can be used for a single delivery, and can also company with other equipment to form a horizontal or inclined conveying system to meet the needs of different production line.
| Model | Belt Width (mm) | Center Distance of Head and Tail Wheel or Drum Wheel (mm) | Diameter of Head and Tail Wheel (mm) | Feed Capacity (t/h) | Feed Size (mm) | Motor Model | Motor Power (kW) |
Weight (kg) |
| 500X1000 | 500 | 1000 | 219 | 10~100 | 0~50 | YCT112- 4B | 0.75 | 266 |
| 500X1300 | 1300 | 10~100 | 0~50 | YCT160 -4A | 2.2 | 345 | ||
| 500X1500 | 1500 | 10~100 | 0~50 | Y2.2-1.0-50-32 | 2.2 | 767 | ||
| 500X2000 | 2000 | 10~100 | 0~50 | Y2.2-1.0-50-32 | 2.2 | 609.4 | ||
| 500X2800 | 2800 | 10~100 | 0~50 | YCT160- 4A | 2.2 | 670 | ||
| 500 X3000 | 3000 | 10~100 | 0~50 | YCT160 -4A | 2.2 | 697 | ||
| 500 X4000 | 4000 | 10~100 | 0~50 | YCT160- 4A | 2.2 | 736 | ||
| 650X1500 | 650 | 1500 | 10~100 | 0~50 | YCT160- 4A | 2.2 | 610 | |
| 650X2600 | 650 | 2600 | 10~100 | 0~50 | YCT160- 4A | 2.2 | 636 | |
| 650X4000 | 650 | 4000 | 10~100 | 0~50 | YCT160- 4A | 2.2 | 893 | |
| 800 X2000 | 800 | 2000 | 15~150 | 0~80 | YCT160- 4A | 2.2 | 721 | |
| 800 X3000 | 800 | 3000 | 15~150 | 0~80 | YCT200- 4B | 7.5 | 857.3 | |
| 800 X4000 | 800 | 4000 | 15~150 | 0~80 | YCT200- 4B | 7.5 | 1012 | |
| 800X4500 | 800 | 4500 | 400 | 15~150 | 0~80 | YCT160- 4A | 2.2 | 1200 |
| 1000X2000 | 1000 | 2000 | 200~450 | 0~80 | YCT160- 4B | 3 | 1549 | |
| 1000X2500 | 2500 | 200~450 | 0 ~100 | YCT160- 4B | 3 | 2105 | ||
| 1000 X6000 | 6000 | 200~450 | 0 ~100 | YCT225- 4A | 11 | 5214 |
