[Introduction]: Concentrating table is a gravity separation equipment of separation different weight mineral by asymmetric reciprocating motion
[Capacity]: 0.1～1.8 t/h
[Improvement]: The cam lever type head is adopted; the stroke is adjusted by changing the position of sliding head on rocker arm; jig frequency is controlled by the smoothing motor pulley.
Concentrating table is applied in roughing, cleaning and scavenging for dressing coarse sand(2- 0.5mm), fine sand (0.5-0.074mm), pulp (-0.074).
| Model | XS 7.6 | XS 4.08 | XS 1.95 | XS 0.5 | |||
| Bed Surface Type | Coarse Sand Bed Surface | Fine Sand Bed Surface | Slurry Bed Surface | 3 Kinds Of Bed Surfaces Selectable | |||
| Beneficiation Area of Bed Surface (m2) | 7.6 | 7.6 | 7.6 | 4.08 | 1.95 | 0.5 | |
| Bed Surface Dimension | Length (mm) | 4500 | 4500 | 4500 | 3000 | 2100 | 1100 |
| Width of Driving End (mm) | 1850 | 1850 | 1850 | 1320 | 1050 | 500 | |
| Width of Concentration End (mm) | 1550 | 1550 | 1550 | 1100 | 850 | 430 | |
| Max. Feed Size (mm) | 2 | 0.5 | 0.074 | Ore Sand -2 Slurry -0.1 | Ore Sand-2 Slurry -0.074 | Ore Sand -2 Slurry -0.074 | |
| Capacity (t/h) | 1 ~1.8 | 0.5 ~1 | 0.3~0.5 | 0.4~1.5 | 0.3~0.8 | 0.05~0.2 | |
| Feed Density (%) | 20 ~30 | 18 ~25 | 15 ~20 | 10 ~30 | |||
| Stroke (mm) | 16 ~22 | 11 ~16 | 8~16 | 6~30 | 12 ~28 | 9~17 | |
| Jig Frequency (r/min) | 220 | 250 | 280 | 210~320 | 250~450 | 280~460 | |
| Water Consumption (t/h) | 0.7 ~1 | 0.4 ~0.7 | 0.4 ~0.7 | 0.3~1.5 | 0.2 ~1 | 0.1~0.5 | |
| Notch Groove Section Shape | Rectangle | Sawtooth Wave | Triangle | Rectangle, Sawtooth Wave and Triangle Selectable | |||
| Motor Power (kW) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 0.55 | |
