Magnetic Drum

[Introduction]: A dry magnetic separator for strong magnetic minerals with coarse particles, and it is also called magnetic pulley.

[Capacity]: 20-600t/h

[Improvement]: Cylinder could be lined with Xinhai wear- resistant rubber to prolong the service life

Get Quote

Online Inquiry

Leave Message

Send Email

ADVANTAGES

Large feeding particle size（450～0mm），no classification before feeding。
High strength and high reliability of the mechanical structure guarantee the normal work of the magnetic drum in a variety of harsh environment.
Permanent magnetic drum is also called magnetic pulley,apparatus magnetic equipment for magnetite ore, mainly used for pre concentration before fine crushing or grinding to remove the gangue, deads and tailings, and the tailings out rate is about 10%.

PRODUCT STRUCTURE

1, It is applied in lean iron roughing after the roughing crushing or middling crushing to remove deads, improve grade, and reduce the load of the next procedure.

2, For not fully reductive raw ore of hematite reduction

3, For the ceramic industry to remove iron and improve the quality of ceramic products

4, For other industries needing to remove iron, such as Burning coal, sand casting, refractory material, etc.

TECHNICAL PARAMETERS

Model & Spec.	Diameter of Cylinder (mm)	Length of Cylinder (mm)	Width of Belt (mm)	Surface Magnetic Density (mt)	Capacity (t/h)	Feed Size (mm)	Total Weight (t)
CTGG-0812	800	1200	1000	300~500	≤100	≤200	2.1
CTGG-0814	800	1400	1200	300~500	≤120	≤200	2.6
CTGG-0816	800	1600	1400	300~500	≤150	≤200	3.2
CTGG-0818	800	1800	1600	300~500	≤180	≤200	3.9
CTGG-1018	1000	1800	1600	300~500	≤270	≤250	4.4
CTGG-1218	1200	1800	1600	300~500	≤350	≤300	5.0
